Caiyuan water pattern dyeing lamp
HT-S001
● Full-spectrum dyeing effect, pure single color, extremely uniform color mixing, red, orange, yellow, green, blue, and purple colors can be changed at will. The mixed white light reaches the standard of natural light. The rich dyeing effect and the water pattern effect are integrated into one, resulting in a symbiotic effect that interprets the water pattern effect of sunlight in the morning, noon, and evening. ● Dual electric ripple speed and water wave texture are adjustable to achieve the water ripple effect required in different environments. ● Independent water pattern color system, the lamp color adopts transitional rotation, and can display multiple color combinations at the same time. ● The lamps can achieve round and specially-made square light emission without borders, and have the function of seamless splicing. The splicing method can be up and down or left and right. ● The water pattern direction of the lamp is the left and right flow direction. When the lamps are spliced, the flow speed of the water pattern can be adjusted synchronously without delay. ● Lake blue superimposed with white light water patterns simulates the water shadow effect of nature.
Quantity:
Light source type: Highly integrated COB lamp beads
Light source chip: OSRAM
Light source power: 200W+10W*9PCS
Lamp color temperature: 7500K
Strobe speed: 1-20Hz/second
Light angle: T30°+R40°/T45°+R60°/T60°+R80°/((optional or customizable combination)
Light spot shape: round/spliced square/left and right flow
Dimming curve: 0-100%
Number of channels: 16 channels
Connection method: hand in hand connection
Number of colors: 5 colors of water pattern + white light (can be customized) and RGBACL six-in-one dyeing fill light
Pattern Rotation: Dual Image Rotation
Display mode: LED digital display
Protection function: overheating protection
Control method: International standard DMX512/manual mode control/master-slave control/
Temperature control: real-time monitoring of light source temperature
Other controls: automatic operation color change
Adjustment angle: up and down adjustment >90°
Ripple direction: left and right flow
Maximum power: 220W+180W/260W
Input voltage: AC110-240V 50/60HZ
Power factor: PFC/0.98
Noise decibel: 0bBi (0.5m)
Working environment:_25°/+35°
Key mode: key mode
Heat dissipation method: conductive heat dissipation
Power device: full power overheating protection device
Adjustment method: manual
Shell material: metal aluminum shell
Internal protection: electronic moisture-proof process
Protection level: IP65
Product size: 287*207*294mm
Product weight: 7.8kg
Light source chip: OSRAM
Light source power: 200W+10W*9PCS
Lamp color temperature: 7500K
Strobe speed: 1-20Hz/second
Light angle: T30°+R40°/T45°+R60°/T60°+R80°/((optional or customizable combination)
Light spot shape: round/spliced square/left and right flow
Dimming curve: 0-100%
Number of channels: 16 channels
Connection method: hand in hand connection
Number of colors: 5 colors of water pattern + white light (can be customized) and RGBACL six-in-one dyeing fill light
Pattern Rotation: Dual Image Rotation
Display mode: LED digital display
Protection function: overheating protection
Control method: International standard DMX512/manual mode control/master-slave control/
Temperature control: real-time monitoring of light source temperature
Other controls: automatic operation color change
Adjustment angle: up and down adjustment >90°
Ripple direction: left and right flow
Maximum power: 220W+180W/260W
Input voltage: AC110-240V 50/60HZ
Power factor: PFC/0.98
Noise decibel: 0bBi (0.5m)
Working environment:_25°/+35°
Key mode: key mode
Heat dissipation method: conductive heat dissipation
Power device: full power overheating protection device
Adjustment method: manual
Shell material: metal aluminum shell
Internal protection: electronic moisture-proof process
Protection level: IP65
Product size: 287*207*294mm
Product weight: 7.8kg
