flat panel light
HT-LED480W
Quantity:
flat panel light
Power input: AC100V-240V, 50/60Hz.
Power consumption: 200W
light source:
YS-480-W--0.5W x 480pcs LED CCT3200K/5600K, color rendering index (CRI): >90
YS-480-WA---0.5W x 240pcsWW(3200K)+ 240pcs CW(5600K) Color Rendering Index (CRI): >90
YS-480-RGBW----0.5W x 480pcs LED 4in1, RGBW
Beam angle: 170°
Cooling system: overall design radiator.
Control panel: LCD display.
Control mode: RDM control; DMX512 control; HSIC dimming system; master-slave synchronization; stand-alone self-propelled program.
Electronic dimming: 0-100% linear dimming; 4 dimming curves optional.
PWM dimming frequency adjustment (1200Hz~20000Hz adjustable)
Color Correction System (CCS): Calibrates the color of each lamp to solve the problem of inconsistent LED color output.
Working environment temperature: -20°C ~ 40°C (- 4°F ~ 104°F)
Lamp body size: L62.2 x H12.8 x W26.4 cm
Net weight: 11.2kg
Power consumption: 200W
light source:
YS-480-W--0.5W x 480pcs LED CCT3200K/5600K, color rendering index (CRI): >90
YS-480-WA---0.5W x 240pcsWW(3200K)+ 240pcs CW(5600K) Color Rendering Index (CRI): >90
YS-480-RGBW----0.5W x 480pcs LED 4in1, RGBW
Beam angle: 170°
Cooling system: overall design radiator.
Control panel: LCD display.
Control mode: RDM control; DMX512 control; HSIC dimming system; master-slave synchronization; stand-alone self-propelled program.
Electronic dimming: 0-100% linear dimming; 4 dimming curves optional.
PWM dimming frequency adjustment (1200Hz~20000Hz adjustable)
Color Correction System (CCS): Calibrates the color of each lamp to solve the problem of inconsistent LED color output.
Working environment temperature: -20°C ~ 40°C (- 4°F ~ 104°F)
Lamp body size: L62.2 x H12.8 x W26.4 cm
Net weight: 11.2kg
